High customer benefit
- Lower LCOE (Levelized Cost Of Energy), lower BOS
(Balance Of System) costs, shorter payback time
- Lower guaranteed degradation in the first year and annually
- Designed for compatibility with existing mainstream systems
Components
- Higher return on investment

High energy efficiency
- Excellent IAM (Incidet Angle Modifier) and low irradiation
performance, confirmed by third-party certifications
- The unique design offers optimised energy production under
shading conditions between rows

High reliability
- Minimised micro-cracks due to innovative non-destructive cutting technology
Technology
- Guaranteed PID resistance through cell process and module material
Control
- Resistant to harsh environments such as salt, ammonia, sand, high
high temperatures and high humidity
- Mechanical performance up to 5400 Pa positive load and 2400 Pa
negative load
- Passed Class C fire test

High power up to 700 W
- Large area cells based on 210 mm silicon wafers and 1/2-cut cells
Technology
- Up to 22.5 % module efficiency with high-density interconnection
Technology
- Multi-busbar technology for better light trapping effect, lower series resistance
series resistance and improved current collection

Product details
MS(670-700)MB-66H Silver frame
Power: 670W
Solar cell: monocrystalline silicon
Cells: 132 cells
Dimensions: 2385×1303×35 mm (93.85×51.29×1.38 inches)
Weight: 35.7 kg
Glass: 3.2 mm (0.13 in.), highly transparent, anti-reflective, heat-resistant glass
Encapsulation material: EVA
Frame: 35 mm (1.38 in.) silver anodised aluminium alloy
Junction box: IP 68 protection (3 bypass diodes)
Cable: Photovoltaic technology cable 4.0mm² (0.006 inch²) Portrait: N 300mm/P 300mm(11.8/11.8 inch) length can be adjusted
Connector: MC4 compatible

Packing:
Pallet: 31 pcs.
40' container: 558 pieces
