Charge / discharge current [A] 25
Max charge / discharge current [A] 50
Nominal voltage [V] 48
Nominal capacity [kWh / Ah] 2.4 / 50
Depth of Discharge [%] 90
Module available capacity [kWh / Ah] 2.16 / 45
Charge voltage [V] 54
Disharge voltage [V] 42
Max charge / discharge current [A] 50
Dimension W x H x D [mm] 480 x 90 x 360
Weight [Kg] 22
Comunication RS485, CAN
Scalability up to 40 units in parallel
Operation Temperature [}C] charge 0 ~ 50
discharge -20 ~ 50
Storage Temperature [}C] -10 ~ 35
Umidity [RH%] 5 ~ 85
Altitude [m] <4000
Protection Class IP20
Operation Life [years] 15+
Life cycles >6.000
Cooling system Natural
Transfer Certificate TÜV, CE, UN38.3, UL1973,
CEI-021
EMC Standard EN62619, IEC62040, CEC
Accredited
Please login with your user name and your password.
Please login with your user name and your password.
Please note: Die Mindestbestellmenge beträgt 1 Pieces, Mindermengen können angefragt werden.
| Per pcs | 305,00 EUR |
| Per kWp |
127,083 EUR
|
| excl. VAT. (22 %) |
Payment:
Advance Payment, Bill, Cash payment
Payment method:
Transfer,
| File name | File type |
|---|---|
| B4850datasheetEN2024 ... | |
| Dynesscampatiblelist ... | |
| TM012-Rev.003-ENG-B4 ... | |
| MSDS B4850 |
