Solar Panel
Attention!
This offer is directed to tradepersons only.
Please log in as a trader, to display all productinformation.
This offer is directed to tradepersons only.
Please log in as a trader, to display all productinformation.
(14 customer ratings)
JINKO SOLAR 585w Ntype 144 cells
TIER 1 MANUFACTURER SOLAR PANEL
ELECTRICAL PARAMETERS
Maximum Power (Pmax/W): 585 W
Maximum Power Voltage (Vmpp/V): 42.52 V
Maximum Power Current (Impp/A): 13.76 A
Open-Circuit Voltage (Voc/V): 51.16 V
Short-Circuit Current (Isc/A): 14.55 A
Module Efficiency (%): 22.65%
Power Tolerance: 0~+3%
NOCT: 45ºC±2ºC
Values at Standard Test Conditions STC: (AM 1.5, Irradiance 1,000 W/m2, Cell Temperature 25ºC)
SPECIFICATIONS
Cell Type: N type Mono-crystalline
Number of cells: 144 (6×24)
Weight: 28 kg
Dimensions: 2278×1134×35mm
Junction Box: IP68 rated
Vico Export Solar Energy
????+34 644 53 71 39
?? europe@vicoexport.com
Please login with your user name and your password.
Please login with your user name and your password.
This offer is directed to tradepersons only
| File name | File type |
|---|---|
| Jinko-Solar-JKM565-5 ... |
