(0 Kundenrezensionen)
Charge / discharge current [A] 25
Max charge / discharge current [A] 50
Nominal voltage [V] 48
Nominal capacity [kWh / Ah] 2.4 / 50
Depth of Discharge [%] 90
Module available capacity [kWh / Ah] 2.16 / 45
Charge voltage [V] 54
Disharge voltage [V] 42
Max charge / discharge current [A] 50
Dimension W x H x D [mm] 480 x 90 x 360
Weight [Kg] 22
Comunication RS485, CAN
Scalability up to 40 units in parallel
Operation Temperature [°C] charge 0 ~ 50
discharge -20 ~ 50
Storage Temperature [°C] -10 ~ 35
Umidity [RH%] 5 ~ 85
Altitude [m] <4000
Protection Class IP20
Operation Life [years] 15+
Life cycles >6.000
Cooling system Natural
Transfer Certificate TÜV, CE, UN38.3, UL1973,
CEI-021
EMC Standard EN62619, IEC62040, CEC
Accredited
Bitte melden Sie sich mit Ihrem Benutzernamen und Ihrem Passwort an.
Bitte melden Sie sich mit Ihrem Benutzernamen und Ihrem Passwort an.
Hinweis: Die Mindestbestellmenge beträgt 1 Stück, Mindermengen können angefragt werden.
| Pro Stück | 280,00 EUR |
| Pro kWp |
116,667 EUR
|
| exkl. MwSt. (22 %) |
Zahlung:
Vorkasse, Rechnung, Bar
Zahlungsart:
Überweisung,
| Dateiname | Dateityp |
|---|---|
| B4850datasheetEN2024 ... | |
| Dynesscampatiblelist ... | |
| TM012-Rev.003-ENG-B4 ... | |
| MSDS B4850 |
Kundenbewertung
Charge / discharge current [A] 25
Max charge / discharge current [A] 50
Nominal voltage [V] 48
Nominal capacity [kWh / Ah] 2.4 / 50
Depth of Discharge [%] 90
Module available capacity [kWh / Ah] 2.16 / 45
Charge voltage [V] 54
Disharge voltage [V] 42
Max charge / discharge current [A] 50
Dimension W x H x D [mm] 480 x 90 x 360
Weight [Kg] 22
Comunication RS485, CAN
Scalability up to 40 units in parallel
Operation Temperature [°C] charge 0 ~ 50
discharge -20 ~ 50
Storage Temperature [°C] -10 ~ 35
Umidity [RH%] 5 ~ 85
Altitude [m] <4000
Protection Class IP20
Operation Life [years] 15+
Life cycles >6.000
Cooling system Natural
Transfer Certificate TÜV, CE, UN38.3, UL1973,
CEI-021
EMC Standard EN62619, IEC62040, CEC
Accredited
| Firmenname | |
| Name des Anbieters | |
| Straße & Hausnummer | |
| PLZ / Ort | |
| Telefon | 00390240702565 |
| info@soirec.com | |
| Website |
| Straße & Hausnummer | Via Keplero 6 |
| PLZ / Ort | 20016 / Pero |
| Land | Italien |
| Pro Stück | 280,00 EUR |
| Pro kWp |
116,667 EUR
|
| exkl. MwSt. (22 %) |
| Dateiname | Dateityp |
|---|---|
| B4850datasheetEN2024 ... | |
| Dynesscampatiblelist ... | |
| TM012-Rev.003-ENG-B4 ... | |
| MSDS B4850 |
exkl. MwSt.
(22 %)-->
