We offer the Growatt TPM-E Three-Phase Smart Meter, designed for monitoring energy flow in compatible Growatt solar PV and energy storage systems.

This direct-connected energy meter supports grid export limitation and self-consumption monitoring. It communicates with compatible Growatt inverters via RS485 and Modbus RTU, making it a practical solution for residential and commercial photovoltaic installations.

Key Features

Three-phase energy metering: Designed for 3-phase, 4-wire (3P4W) electrical systems.

Export limitation: Supports export power control when integrated with a compatible Growatt inverter.

Self-consumption monitoring: Helps monitor energy flow within the solar installation.

LCD display: Enables convenient local readings and status checks.

Direct connection: Rated for 10 A nominal current and up to 100 A maximum current.

Easy installation: Designed for standard 35 mm DIN-rail mounting.

Communication: RS485 interface with Modbus RTU protocol.

Included accessory: Standard 15 m RS485 communication cable.

Certification: CE listed in the manufacturer's datasheet.

Technical Specifications

Specification

Value

Manufacturer

Growatt

Model

TPM-E

Meter type

Three-phase smart energy meter

Grid configuration

3P4W

Input voltage

320–520 V AC (line-to-line)

Nominal current

10 A

Maximum current

100 A

Operating frequency

50/60 Hz

Specified frequency range

45–56 Hz

Voltage measurement accuracy

0.5%

Current measurement accuracy

0.5%

Power measurement accuracy

1%

Frequency measurement accuracy

0.2%

Communication interface

RS485

Communication protocol

Modbus RTU

Baud rate

9600 bps

Display

LCD

Mounting

35 mm DIN rail

Dimensions (W × D × H)

72 × 94.5 × 65 mm

Weight

398 g

Operating temperature

?25}C to +55}C

Storage temperature

?40}C to +70}C

Operating humidity

0–90%, non-condensing

Protection rating

IP51 (indoor use)

Certification

CE

Package Contents

1 × Growatt TPM-E Three-Phase Smart Meter

1 × 15 m RS485 communication cable

User documentation, where included in the supplied package

Condition and Availability

Condition: New and unused.

Available from stock in Sweden. Bulk quantities may be available for installers, solar distributors and other B2B customers.

Please contact us for current stock availability, bulk pricing and shipping options.

Important: Please verify compatibility with your specific Growatt inverter model before ordering.
